Bronto S125XDT Aerial

Call for Pricing

ETA Q3 2023

PETERBILT 567

• Paccar MX-15 engine 510@1600 GV@2200 1850@1000
• Allison 4700 RDS-P transmission
• Paccar FX-20 front axle 20,000 lbs; Meritor RT46-160 rear axle 46,000 lbs
• 135 gallon fuel tank

PLATFORM

• Working height 125 ft
• Height to working cage bottom 118 ft
• Working outreach 88.5 ft
• Cage load 1,543 lbs
• Up-and-over capability 34.5 ft
• Working cage slewing +-90 degrees
• Continuous rotation
• Typical weight with chassis 18 tons
• Aluminum sides on the decking
• One-sided outrigger operation
• Amber flashing light on work platform
• Backup alarm
• (2) GO lights, (2) LED ECCO strobe lights front, (2) at rear chassis
• (2) LED work lights, (1) each side of boom
• (2) aluminum underbody boxes
• PTO and pump
• (1) Aero motive ground reel GR 1000L
• Arctic Fox tank heater
• Reelcraft hose reel 50′ x 3/8″ hose
• Exterior white; interior gray

*Picture for reference only. Refer to drawing for accurate unit depiction.

Download sales sheet PDF
